Horizontal bone augementation with a collagenic bone lamina

Prof. Tiziano Testori
Initial situation

A female patient (35 years old) shows a horizontal defect in the esthetic area.

Used biomaterials
  • Lamina
  • Evolution
The patient shows a severe defect in the esthetic area

The patient shows a severe defect in the esthetic area

The patient shows a severe defect in the esthetic area

The patient shows a severe defect in the esthetic area

A sticky bone is used to reconstruct the bone horizontally

A sticky bone is used to reconstruct the bone horizontally

Lamina® is used to reconstruct the missing buccal bone. Lamina® has been fixed to avoid micromovents that may jeopardise new bone formation.

Lamina® is used to reconstruct the missing buccal bone. Lamina® has been fixed to avoid micromovents that may jeopardise new bone formation.

A connective tissue graft is harvested from the palate.

A connective tissue graft is harvested from the palate.

Evolution collagen membranes are used to protect the Lamina® from contamination. CTG is used according to the connective tissue platform protocol

Evolution collagen membranes are used to protect the Lamina® from contamination. CTG is used according to the connective tissue platform protocol

PRF membranes are used to boost soft tissue healing

PRF membranes are used to boost soft tissue healing

Soft tissue flaps are sutured

Soft tissue flaps are sutured

At the time of implant placement, soft tissues have healed uneventfully.

At the time of implant placement, soft tissues have healed uneventfully.

At the time of implant placement, soft tissues have healed uneventfully.

At the time of implant placement, soft tissues have healed uneventfully.

At the time of implant placement, soft tissues have healed uneventfully.

At the time of implant placement, soft tissues have healed uneventfully.

Implants are firmly anchored to newly formed bone. No signs of peri-implantitis are detected

Implants are firmly anchored to newly formed bone. No signs of peri-implantitis are detected

5-year follow up. Implants are firmly anchored to newly formed bone. No signs of peri-implantitis are detected.

5-year follow up. Implants are firmly anchored to newly formed bone. No signs of peri-implantitis are detected.
